GB-020F
Inquiry
PREV
- Features
- Description
- Specifications
- 1. Comprehensive production line consisting of 19 integrated machine units.
- 2. Requires an operational workforce of 24 personnel.
- 3. Defined production capacity: 20 wooden hangers per minute.
- 4. Optional integration of a Central Control System (CCS).
- 5. Optional Automated Defect Inspection equipment to achieve a fully automated production architecture.
- This equipment series constitutes a complete production line engineered specifically for the manufacturing of wooden hangers. The baseline system architecture consists of 19 individual machines requiring an operational workforce of 24 personnel, delivering a fixed production capacity of 20 units per minute. The system configuration is scalable, allowing for the integration of an optional central control system and defect inspection equipment to upgrade the facility into a fully automated manufacturing environment.
| MODEL | GB-020F |
| The max. sizes of cut | 320 x 55 x 150 mm |
| The cutting angle | 90 / -90 degree |
| The band sawblade sizes | 5900 x 127 x 0.8 mm |
| The saw wheel diameter | 890 mm |
| The saw wheel speed | 750 R.P.M |
| The sawblade speed | 2000 mt/min |
| The X/Y axis feed speed | 0/70 mt/min / 0/20 mt/min |
| The X/Y/ C axis motor | 3 kw/ 1 kw/ 0.4 kw |
| The band saw blade motor | 15 HP |
| The conveyor motor | 0.37 kw |
| The total of power | 16.4 kw |
| The dust hood diameter | 100 mm x 2 |
| The working air pressure | 6 bar |
| The outfeed conveyor | 1 set |
| The net weight/ gross weight | 3400 KGS/ 3800 KGS |
| The machine dimensions | 5550 x 2350 x 2600 mm |
